Frame

• Frame: Alpha Platinum Aluminum, internal cable routing, dealer-removable battery, rack and fender mounts, post-mount disc brake mount, kickstand mount.

Fork

• Fork: FX+ 7, carbon legs, hidden fender mounts, flat-mount disc brake, internal cable routing, 12 × 100 mm thru axle.

Wheels

• Front hub: Formula alloy, CenterLock disc, 12 × 100 mm thru axle
• Front axle: Bontrager Switch thru axle
• Rear hub: Bontrager alloy, sealed bearings, CenterLock disc, Shimano 11-speed freehub, 12 × 142 mm thru axle
• Rear axle: Bontrager Switch thru axle
• Rims: Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve
• Spokes: 14G stainless steel, black
• Tires: Bontrager H2 Hard Case Lite, wire bead, 30 TPI, 700 × 40 mm
• Maximum tire size: 700 × 42 mm

E-System

• Battery: TQ, 360 Wh
• Charger: TQ, 4 A
• Computer: TQ LED display with Bluetooth and ANT+ connectivity
• Motor: TQ-HPR50
  • Maximum torque: 50 Nm
  • Maximum continuous rated power: 250 W
  • Peak power: 300 W
• E-bike classification: Class 1

Drivetrain

• Shifter: Shimano U6000, 10-speed
• Rear derailleur: Shimano CUES U6000 GS
• Crankset: ProWheel alloy, 46T Narrow-Wide chainring, 170 mm crank arm length, ISIS spline
• Cassette: Shimano CUES LG400, LINKGLIDE, 11–48T, 10-speed
• Chain: Shimano LG500, 9/10/11-speed
• Pedals: Bontrager City pedals
• Maximum chainring size: 1×: 46T

Components

Saddle

• Saddle: Bontrager Verse Comp, steel rails, 165 mm width

Seatpost

• Seatpost: Bontrager Comp, 6061 alloy, 31.6 mm diameter, 8 mm offset, 400 mm length

Integrated Handlebar / Stem

• Sizes XS, S and M:
  • Bontrager integrated handlebar/stem
  • 15 mm virtual handlebar rise
  • Width: 640 mm
  • Stem rise: 0°
  • Virtual stem length: 90 mm
• Size L:
  • Bontrager integrated handlebar/stem
  • 15 mm virtual handlebar rise
  • Width: 680 mm
  • Stem rise: 0°
  • Virtual stem length: 90 mm

Grips

• Grips: Trek Line Ergonomic Pro, lock-on

Brakes

• Brakes: Shimano hydraulic disc brakes, RS600 levers, RS405 calipers

Brake Rotors

• Sizes XS, S, M and L:
  • Shimano SM-RT64, CenterLock, 180 mm
  • Shimano RT-EM600, CenterLock, 160 mm
• Maximum rotor size: 180 mm front and rear

Accessories

Lights

• Sizes XS, S, M and L:
  • Spanninga GLOW XE for e-bike
  • Herrmans H-Black MR9-E

Kickstand

• Kickstand: Adjustable-length rear-mounted alloy kickstand

Rear Rack

• Rear rack: MIK-compatible alloy rear rack

Fender

• Fender: Trek FX+ 7 Rear Fender

Weight

• Weight in size M: 18.70 kg

Weight Limit

• Maximum total weight limit: 136 kg, including the weight of the bicycle, rider, and cargo.
