Frame: Carbon frame, 115mm travel, UDH, Eagle Transmission compatible, Ride Aligned™
Fork: RockShox SID Ultimate 3P, 120mm, 44mm offset
Rear Shock: RockShox SIDLuxe Ultimate, 190x42.5mm, standard
Rear Shifter: Shimano XTR SW-M9250-IR, I-Spec
Rear Derailleur: Shimano XTR RD-M9250 Di2, 12-speed, SGS
Crankset: Shimano Deore XT FC-M8200, 34T, CL55, 165mm (S1), 170mm (S2, S3), 175mm (S4, S5)
Bottom Bracket: Shimano BB-MT501, BSA 73mm
Cassette: Shimano XTR CS-M9200-12, 10-51T, 12-speed
Chain: Shimano XTR CN-M9100, 12-speed
Front Brake: Shimano Deore XT BR-M8220, metal pads
Front Rotor: Shimano SM-RT66, 180mm, 6-bolt
Rear Brake: Shimano Deore XT BR-M8220, metal pads
Rear Rotor: Shimano SM-RT66, 160mm, 6-bolt
Brake Levers: Shimano Deore XT BL-M8220
Handlebar: Race Face ERA35, 760mm (S1, S2) / 780mm (S3, S4, S5), 20mm rise
Stem: Alloy CNC, 50mm length, 35mm clamp
Seatpost: TranzX YSI36, 31.6mm, 120mm (S1, S2) / 150mm (S3) / 170mm (S4) / 200mm (S5)
Headset: FSA No.42/48ACB integrated, tapered 1-1/8" – 1.5"
Saddle: Fizik Terra Ridon, MG rails
Grips/Tape: WTB Wavelength
Seatpost Clamp: Norco alloy nutted clamp, 34.9mm ID
Front Hub: Zipp 1Zero Hitop S, 15x110mm Boost, 6-bolt
Rear Hub: Zipp 1Zero Hitop S, 12x148mm Boost, Microspline, 6-bolt
Rims: Zipp 1Zero Hitop S carbon, 30mm internal width, 29"
Front Tire: Maxxis Rekon, 3C Maxx Terra EXO, 29x2.40"
Rear Tire: Maxxis Rekon Race, 3C Maxx Speed EXO, 29x2.40"
Rear Axle: 148mm x 12mm thru-axle, L174, TL13, M12x1.3
Spokes/Nipples: CX-Sprint
Valves: Zipp tubeless valves
Sealant: Stan’s, 250ml
Weight: 11.56 kg (25.5 lbs)
Weight Size: S3
